Rode NT5 Small-diaphragm Condenser Microphone - Matched Pair

Rode NT5 Small-diaphragm Condenser Microphone - Matched Pair

• Compact 1/2" cardioid condenser microphone.
• Description

• The NT5 is a premium small-diaphragm condenser microphone designed for critical recording applications. Featuring a 1/2-inch gold-sputtered cardioid condenser capsule, it delivers a smooth, balanced sound with very low self-noise. Its exceptionally accurate cardioid polar pattern and wide frequency response make the NT5 ideal for recording everything from acoustic instruments to drum overheads and cymbals to live performances and dialogue on-location.

  Expanding the NT5's versatility, an interchangeable omnidirectional capsule (NT45-O) is also available separately.

  The NT5 is also available as a certified match pair for stereo recording.

  FEATURES

  • Premium small-diaphragm condenser microphone
  • 1/2-inch gold-sputtered cardioid condenser capsule
  • Very low self-noise
  • Exceptionally accurate cardioid polar pattern and wide frequency response
  • Available as a certified match pair for stereo recording
  • 10-year warranty
  • Specification

  • Acoustic & Electrical Specifications

    Active Electronics

    JFET impedance converter with bipolar output buffer

    ---

    Capsule

    0.50"

    ---

    Polar Pattern

    Cardioid

    ---

    Address Type

    End

    ---

    Frequency Range

    20Hz - 20kHz

    ---

    Output Impedance

    100Ω

    ---

    Maximum SPL

    143dB SPL

    ---

    Maximum Output Level

    13.9mV (@ 1kHz, 1% THD into 1KΩ load)

    ---

    Sensitivity

    -38.0dB re 1 Volt/Pascal (12.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz

    ---

    Equivalent Noise Level (A-Weighted)

    16dBA

    ---

    Power Requirements

    P24 and P48

    ---

    Output Connection

    XLR

    ---

    Mechanical Specifications

    Weight (g)

    101

    ---

    Dimensions (mm)

    20 (H) x 118 (W) x 20 (D)
